6000W Fiber Laser Cutting Machine
6000W fiber laser cutting machine for heavy industrial applications. Cuts carbon steel to 20mm, stainless steel to 14mm with ±0.05mm repeatability. 2000x4000mm bed, 50000+ hour tube life, servo-driven XY table, CE certified.
Highlights
- Cuts carbon steel up to 20mm and stainless steel up to 14mm
- Extended 2000 x 4000mm working bed for large components
- CE certified for European industrial safety compliance
- Automatic nozzle height adjustment for consistent quality
- Servo motor-driven XY table for smooth motion
- 50000+ hour sealed tube life reduces operating costs
- Job scheduler handles batch and complex cutting sequences
Specifications
| Laser Power | 6000W |
|---|---|
| Max Cutting Thickness | Carbon Steel 20mm, Stainless Steel 14mm |
| Working Area | 2000 x 4000 mm |
| Repeatability | +/- 0.05 mm |
| Tube Lifespan | 50000+ hours |
| Certifications | CE Certified |
Product Detail
6000W Fiber Laser Cutting Machine
The 6000W Fiber Laser Cutting Machine from Shandong Xinhong CNC is built for contract manufacturers and job shops that process thick plate daily. It cuts carbon steel to 20mm and stainless steel to 14mm with ±0.05mm repeatability across a 2000×4000mm working bed - large enough for structural components, machinery frames, and oversized fabrications without splitting the plate. The sealed fiber tube runs 50,000+ hours between maintenance intervals, and the servo motor-driven XY table with automatic nozzle height adjustment maintains consistent cut quality across varying material thicknesses within the same job.
Buyer Pain Points & Solutions
Core Advantages
Technical Specifications
| Parameter | Value |
|---|---|
| Laser Power | 6000W |
| Laser Source | Sealed fiber tube (IPG / RAYCUS / GW optional) |
| Max Cutting Thickness (Carbon Steel) | 20mm |
| Max Cutting Thickness (Stainless Steel) | 14mm |
| Working Area | 2000 × 4000 mm |
| Repeatability | ±0.05 mm |
| Tube Lifespan | 50,000+ hours |
| Drive System | Servo motor-driven XY table |
| Nozzle Control | Automatic height adjustment |
| Certifications | CE Certified |
Application Industries
Manufacturer Backing
Manufactured by Shandong Xinhong CNC Technology Co., Ltd., an ISO 9001:2015-certified and CE-compliant fiber laser equipment manufacturer. Xinhong's product line spans 1000W to 30000W fiber laser cutting systems, welding machines, and auxiliary equipment. The company partners with IPG (USA), RAYCUS, and GW for laser sources, ensuring parts availability and beam quality consistency. Technical documentation, operation manuals, and operator training are provided with every machine. Custom configurations for bed size, laser source brand, and auxiliary systems are available on request.
FAQ
What materials and thicknesses can the 6000W machine handle?
Carbon steel up to 20mm and stainless steel up to 14mm. The system also processes aluminum and other alloys at reduced thicknesses. Cutting speed varies with material type and thickness - performance data sheets are available on request.
How does the automatic nozzle height adjustment work?
The cutting head uses capacitive sensing to track the material surface in real time. As the nozzle moves across the sheet, it automatically adjusts height to maintain the optimal focal distance, compensating for sheet warping, surface irregularities, and thickness transitions within the same cutting program.
Can the 2000x4000mm bed handle custom plate sizes?
The standard bed accommodates plates up to 2000×4000mm. For larger or non-standard sizes, contact us to discuss custom bed configurations. Plates larger than the bed can be processed in sections if needed.
What is the maintenance schedule for the sealed fiber tube?
The sealed fiber tube requires minimal maintenance compared to CO2 lasers - no gas refills or mirror alignment. Scheduled maintenance primarily involves checking cooling system performance, cleaning protective lenses, and inspecting the cutting head. The tube is rated for 50,000+ hours of operation.
Is the machine CE certified for European export?
Yes, Xinhong's fiber laser cutting machines are CE certified for European industrial safety compliance, meeting requirements for direct export to European markets.
