XINHONG
1000W Fiber Laser Cutting Machine
Industrial 1000W fiber laser cutting machine with large format bed (3000x1500mm or 4000x2000mm). Cuts 1-12mm thickness across stainless steel, carbon steel, copper, and titanium alloy. ±0.05mm/m positioning accuracy, 120m/min rapid speed.
Get a QuoteSpecifications
| Y-Axis Travel | 3000mm / 4000mm |
|---|---|
| Electricity Demand | 380V / 50Hz or 380V / 60Hz |
| Appearance Size | 4200x8000x1900mm |
| Laser Power | 1000W |
| Laser Type | Fiber laser IPG / RAYCUS / GW |
| Plate Processing Formation | 3000mm×1500mm / 4000mm×2000mm |
| X-Axis Travel | 1500mm / 2000mm |
| Cut Thickness | 1mm~12mm |
| Repeat Positioning Accuracy | ≤ ±0.03mm |
| Positioning Accuracy | ≤ ±0.05mm/m |
| Empty Acceleration | 1.2g |
| Processing Acceleration | 0.8g |
| Applicable Materials | Stainless steel, carbon steel, copper plate, alloy steel, spring steel, galvanized plate, aluminized plate, titanium alloy, alloy plates and pipes |
| Maximum Empty Speed | 120m/min |
| Machine Weight | 3000kg / 5000kg |
Product Detail
1000W Fiber Laser Cutting Machine
The 1000W Fiber Laser Cutting Machine from XINHONG pairs a precision fiber laser source with a large-format cutting bed, giving fabricators the plate capacity of a mid-range machine at entry-level power. Available in 3000×1500mm or 4000×2000mm table formats, it handles material thicknesses from 1mm to 12mm across stainless steel, carbon steel, copper plate, alloy steel, spring steel, galvanized plate, aluminized plate, and titanium alloy - in both sheet and pipe form. With ≤±0.05mm/m positioning accuracy, ≤±0.03mm repeatability, and 120m/min rapid traverse speed, this machine delivers production-grade output for job shops scaling up from manual cutting or CO2 lasers.
Buyer Pain Points & Solutions
Core Advantages
Technical Specifications
| Parameter | Value |
|---|---|
| Laser Power | 1000W |
| Laser Type | Fiber laser (IPG / RAYCUS / GW) |
| Cut Thickness Range | 1mm – 12mm |
| Applicable Materials | Stainless steel, carbon steel, copper plate, alloy steel, spring steel, galvanized plate, aluminized plate, titanium alloy |
| Processing Format (Option 1) | 3000mm × 1500mm |
| Processing Format (Option 2) | 4000mm × 2000mm |
| X-Axis Travel | 1500mm / 2000mm |
| Y-Axis Travel | 3000mm / 4000mm |
| Positioning Accuracy | ≤ ±0.05mm/m |
| Repeat Positioning Accuracy | ≤ ±0.03mm |
| Maximum Empty Speed | 120m/min |
| Empty Acceleration | 1.2g |
| Processing Acceleration | 0.8g |
| Electricity Demand | 380V / 50Hz or 380V / 60Hz |
| Machine Weight | 3000kg / 5000kg (depending on format) |
| Appearance Size | 4200 × 8000 × 1900mm |
Application Industries
Manufacturer Backing
Manufactured by Shandong Xinhong CNC Technology Co., Ltd., an ISO 9001:2015-certified and CE-compliant fiber laser equipment manufacturer. Xinhong's product line spans 1000W to 30000W fiber laser cutting systems, welding machines, and auxiliary equipment. The company partners with IPG (USA), RAYCUS, and GW for laser sources, ensuring parts availability and beam quality consistency across global markets. Technical documentation, operation manuals, and operator training are provided with every machine. Custom configurations for table format, laser source brand, and auxiliary systems are available on request.
FAQ
What is the difference between the two table formats?
The 3000×1500mm format suits standard sheet metal processing and fits in most workshop layouts. The 4000×2000mm format accommodates oversized plates from steel mills without pre-cutting, reducing material waste. Choose based on your typical material supply size and available floor space.
Can this machine cut pipe as well as plate?
Yes. The system is configured for both plate and pipe processing. Contact us to specify the pipe diameter range and rotational fixture requirements for your application.
What is the maximum cutting thickness for different materials?
The machine cuts 1-12mm total range. Actual maximum thickness depends on material type: carbon steel reaches the full 12mm, stainless steel approximately 8-10mm, and copper/titanium alloys less. Cutting speed decreases with thickness. Detailed performance data is available on request.
Which laser source should I choose - IPG, RAYCUS, or GW?
IPG (USA) offers the highest beam quality and is preferred for demanding applications. RAYCUS and GW provide excellent value with reliable performance for standard cutting work. All three are supported with global parts availability. We can help you select based on your budget and application requirements.
Is the machine CE certified for European export?
Yes, Xinhong's fiber laser cutting machines are CE certified for European industrial safety compliance, meeting requirements for direct export to European markets.
