PSA Nitrogen Generator for Laser Cutting
PSA nitrogen generator for fiber laser cutting. 99.9% purity, 10-80 m³/h flow rate, 0.6-0.8 MPa. Eliminates bottled nitrogen costs with 6-12 month ROI. CE certified, compact footprint.
Highlights
- Produces 99.9% pure nitrogen from compressed air input
- Adjustable flow rate from 10 to 80 cubic meters per hour
- Dual filtration and membrane separation technology
- CE safety certified with low noise operation below 75dB
- Automatic pressure regulation with manual override controls
- Filter cartridge replacement only monthly maintenance requirement
- ROI achieved in 6-12 months versus bottled nitrogen costs
Specifications
| Nitrogen Purity | 99.9% |
|---|---|
| Flow Rate Range | 10-80 cubic meters per hour |
| Inlet Pressure | 0.6-0.8 MPa |
| Filtration Stages | Dual Filtration + Membrane Separation |
| Noise Level | Below 75 dB |
| Certifications | CE Safety Certified |
Product Detail
PSA Nitrogen Generator for Laser Cutting
Bottled nitrogen is one of the highest recurring costs in fiber laser cutting of stainless steel and aluminum. The PSA Nitrogen Generator from Shandong Xinhong CNC eliminates that cost by producing 99.9% pure nitrogen on-site from compressed air. With output flow rates from 10 to 80 cubic meters per hour, it matches the assist gas demand of fiber laser cutting machines from 1000W to 12000W. Integrated membrane separation technology and dual filtration stages remove moisture and particulates, ensuring consistent cutting performance on stainless steel and aluminum. Typical payback period is 6-12 months compared to bottled nitrogen supply, after which the only running expense is compressed air consumption.
Buyer Pain Points & Solutions
Core Advantages
Technical Specifications
| Parameter | Value |
|---|---|
| Nitrogen Purity | 99.9% |
| Flow Rate Range | 10 – 80 cubic meters per hour |
| Inlet Pressure | 0.6 – 0.8 MPa |
| Separation Technology | PSA + membrane separation |
| Filtration | Dual filtration stages (moisture + particulate) |
| Pressure Regulation | Automatic with manual override |
| Noise Level | Below 75 dB |
| Maintenance | Monthly filter cartridge replacement |
| Certifications | CE Safety Certified |
Application Industries
Manufacturer Backing
Manufactured by Shandong Xinhong CNC Technology Co., Ltd., an ISO 9001:2015-certified and CE-compliant fiber laser equipment manufacturer. This nitrogen generator integrates with Xinhong's fiber laser cutting systems (1000W-30000W) for a complete on-site gas supply solution. Technical documentation, operation manuals, and installation guidance are provided. Custom flow rate configurations are available to match specific cutting machine requirements.
FAQ
How does PSA nitrogen generation work?
PSA (Pressure Swing Adsorption) uses carbon molecular sieves to separate nitrogen from oxygen in compressed air. At high pressure, the sieve adsorbs oxygen and lets nitrogen pass through. The system alternates between two sieve beds, producing a continuous nitrogen supply at 99.9% purity without consumables.
What size air compressor do I need?
The generator requires a compressed air supply at 0.6-0.8 MPa inlet pressure. The required compressor capacity depends on your nitrogen flow rate setting. Contact us with your cutting machine power level and typical daily usage, and we'll specify the appropriate compressor size.
How long until the system pays for itself?
Typical payback period is 6-12 months compared to bottled nitrogen costs, depending on your nitrogen consumption volume and local bottled gas pricing. After payback, running expenses are limited to compressed air electricity consumption and monthly filter cartridge replacement.
Is 99.9% purity sufficient for laser cutting?
Yes. 99.9% nitrogen purity is the standard for fiber laser cutting of stainless steel and aluminum, producing bright, oxide-free cut edges. For applications requiring ultra-high purity (99.999%), higher-tier PSA configurations are available on request.
What maintenance does the system require?
Monthly filter cartridge replacement is the primary maintenance task. The PSA sieve beds have a long service life (typically 5+ years) under normal operating conditions. No daily maintenance is required - the system operates automatically once configured.
